CFL 62 LD Systems · Ceiling Loudspeakers
6.5" frameless 2-way in-wall speaker
Overview
CFL 62 at a Glance
6.5'' frameless 2-way in-wall speaker
Description
About the CFL 62
Manufacturer detail for the CFL 62 by LD Systems.
Technical Overview
The CONTRACTOR CFL 62 is an frameless in-wall speaker for unobtrusive installation in walls. The almost flush front grille with magnetic mount covers a 6.5" woofer and 1.2" tweeter that feature a clear sound and high speech intelligibility. Its frequency response extends to 20 kHz; the sound pressure level is 88 dB at 1 W /1 m, with a power capacity of 60 watts of continuous power. Secure swivels enable fast and easy assembly of the CFL 62. The in-wall speaker is designed for a wide scope of applications, providing a discreet sound in hotels, restaurants, bars, lounges, training and conference rooms, shopping centres and even at home.
For ELA systems, the CFL 62 is available as a 100 Volt version (CFL 62 100 V) with three taps for 6, 12, and 24 watts.
Specifications
Technical Specifications
Full published figures for the CFL 62 by LD Systems.
- Product type
- Installation Loudspeakers
- Type
- Ceiling-mounted Loudspeaker
- Version
- Wall installation speaker
- Speaker type
- 2-way speaker
- Color
- Black, white grille
- Woofer dimensions
- 6.5 "
- Woofer dimensions (mm)
- 165 mm
- Tweeter dimensions
- 1.2 "
- Tweeter dimensions (mm)
- 30 mm
- Cut-out measurement
- 210 mm
- Mounting depth
- 81 mm
- Min. Material Thickness
- 3 mm
Show all 22 specifications Show fewer specifications
- Max. Material Thickness
- 15 mm
- Impedance (low-impedance)
- 8 Ohm(s)
- Frequency response
- 70 - 20000 Hz
- Sensitivity (1 W / 1 m)
- 88 dB
- Low-impedance rated load (RMS)
- 60 W
- Depth
- 86 mm
- Diameter
- 234 mm
- Weight
- 1,56 kg
- Length
- 86 mm
- Power Consumption
- 60 W
Documentation
Downloads
Datasheets, manuals and drawings for the CFL 62.
