Description
Detailed information about the C4.8T by Martin Audio
Technical Overview
C4.8T's configuration easily outperforms coaxial stalk-mounted tweeter or single driver arrangements in terms of wide dispersion and smooth off-axis frequency response. The exceptionally wide dispersion of the C4.8T makes it particularly suitable for installation in low ceilings where significantly
Technical Specifications
Complete technical specifications and documentation for the C4.8T by Martin Audio
Technical Drawing
Product Specifications
| Name | Value |
|---|---|
| TYPE | Ceiling mounted, two-way vented enclosure |
| FREQUENCY RESPONSE (5) | 100Hz-20kHz ± 3dB -10dB @ 80Hz |
| DRIVER | 4" (100mm) UL94V-0 PP bass driver 0.8" (19mm) dome tweeter |
| RATED POWER (2) | 40W AES, 160W peak |
| SENSITIVITY (8) | 86dB |
| MAXIMUM SPL (9) | 100dB continuous, 106dB peak |
| NOMINAL IMPEDANCE | 16Ω |
| DISPERSION (-6dB) | 180° conical up to 10kHz |
| CROSSOVER | 5kHz passive |
| ENCLOSURE | Steel backcan |
| FINISH | Bezel & grille – white UV resistant (Overpaintable) Backcan – zinc plated |
| PROTECTIVE GRILLE | Perforated steel |
| CONNECTORS | Rising clamp plug and socket |
| ACCESSORIES (included) | 25W 70/100V line transformer Tile rails C bracket Paint mask Cut-out template |
| VOLTAGE TAPS | 100V – 25W, 12.5W, 6W 70V – 25W, 12.5W, 6W, 3W |
| DIMENSIONS | (OD) 205mm x (D) 131mm (OD) 8.1ins x (D) 5.1ins |
| CUT-OUT DIAMETER | 178mm (7.01 ins) |
| WEIGHT | 2.6kg (5.7lbs) |
