X10B - Professional Audio & Lighting Equipment Description
Detailed information about the X10B by Martin Audio
Technical Overview
It has a multitude of professional applications — from distributed sound reinforcement, HoW and AV events to frontfill/infill and use as an unobtrusive stage monitor. With a maximum SPL of 124dB @ 1m, it is uniquely placed to meet the foreground requirements of music bars and clubs that require upfr
X10B Technical Specifications
Complete technical specifications and documentation for the X10B by Martin Audio
Technical Drawing
Product Specifications
| Name | Value |
|---|---|
| TYPE | Compact, passive two-way system |
| FREQUENCY RESPONSE (5) | 65Hz-20kHz ± 3dB, -10dB @ 55Hz |
| DRIVER | LF: 10” (250mm)/2.5” (63.5mm) voice coil, ferrite motor system HF: 1” (25mm) exit/1.4” (35mm) voice coil, polyimide dome compression driver |
| RATED POWER (2) | 250W AES, 1000W peak |
| SENSITIVITY (8) | 94dB |
| MAXIMUM SPL (9) | 118dB continuous, 124dB peak |
| NOMINAL IMPEDANCE | 8Ω |
| DISPERSION (-6dB) | 90° H x 50° V (user-rotatable) |
| CROSSOVER | 2.4kHz passive |
| ENCLOSURE | Multi-angle birch/poplar ply |
| FINISH | Black textured paint |
| PROTECTIVE GRILLE | Black perforated steel with scrim cloth backing |
| CONNECTORS | 2 x NL4 type |
| PIN CONNECTIONS (INPUT) | 1+/1- |
| PIN CONNECTIONS (LINK) | 1+/- to 1+/- |
| FITTINGS | 19 x M8 inserts, pole-mount socket, 1 x bar handle |
| DIMENSIONS | (W) 324mm x (H) 522mm x (D) 289mm (W) 12.8ins x (H) 20.6ins x (D) 11.4ins |
| WEIGHT | 14kg (30.9lbs) |
| ACCESSORIES | Wall bracket, eyebolts |
