Vision VPC200CW-2045
Vision

VPC200CW-2045 Vision · Theatrical Lighting

200W white COB LED enabling 1-20 flashes per second with up to 18,000 lumens and more than 50,000 hours of LED life
Request a Quote Data Sheet
Reference VPC200CW-2045 Brand Vision

Specifications

Technical Specifications

Full published figures for the VPC200CW-2045 by Vision.

LED
COB, 200W, white
Luminous lux
17,000 - 18,000 lumens
Beam angle
20° and 45°
Strobe
1-20 flash per second
Color temperature
3200K / 5600K
Control mode
International standard DMX 512 signal
Channel mode
1, 2 channels
Display
LCD screen
Protection grade
IP20
CRI
85Ra or 95Ra
LED life
More than 50,000 hours
Cooling system
Heat pipe without noise fan
Show all 15 specifications Show fewer specifications
Environment temperature
-20°C - 45°C
Power supply
AC100V-240V, 50/60Hz
Power consumption
250W

Technical Drawing

Technical drawing for VPC200CW-2045
Download PDF

Documentation

Downloads

Datasheets, manuals and drawings for the VPC200CW-2045.

Data Sheet PDF Technical Drawing PDF CAD Drawing DWG DMX Chart PDF
