Description
Detailed information about the C8.1T by Martin Audio
Technical Overview
The enclosure is ported to extend the low frequency performance and the 5-point mounting system ensures that installation is fast and secure. Input and link terminals make paralleling units a simple operation and a steel cover plate protects the input connector against fire. These products comply w
Technical Specifications
Complete technical specifications and documentation for the C8.1T by Martin Audio
Technical Drawing
Product Specifications
| Name | Value |
|---|---|
| TYPE | Ceiling mounted, two-way vented enclosure |
| FREQUENCY RESPONSE (5) | 80Hz-18kHz ± 3dB -10dB @ 50Hz |
| DRIVER | 8" (200mm) UL94V-0 PP bass driver 1" (25mm) dome tweeter |
| RATED POWER (2) | 125W AES, 500W peak |
| SENSITIVITY (8) | 91dB |
| MAXIMUM SPL (9) | 110dB continuous, 116dB peak |
| NOMINAL IMPEDANCE | 16Ω |
| DISPERSION (-6dB) | 90° conical up to 7kHz |
| CROSSOVER | 3kHz passive |
| ENCLOSURE | Steel backcan |
| FINISH | Bezel & grille – white UV resistant (Overpaintable) Backcan – zinc plated |
| PROTECTIVE GRILLE | Perforated steel |
| CONNECTORS | Rising clamp plug and socket |
| ACCESSORIES (included) | 60W 70/100V line transformer Tile rails C bracket Paint mask Cut-out template |
| VOLTAGE TAPS | 100V – 60W, 30W, 15W 70V – 60W, 30W, 15W, 7.5W |
| DIMENSIONS | (OD) 354mm x (D) 258mm (OD) 13.9ins x (D) 10.2ins |
| CUT-OUT DIAMETER | 308mm (12.14 ins) |
| WEIGHT | 6.7kg (14.8lbs) |
